Specifications
Key Features:
- 6 cylinder Volvo engine
- Parker hydraulics
- Delphi controllers
- Kessler drive axles
- ZF gearbox
Specifications:
| Model | CPCD160EC2-CZ/DZ (2 layers) | CPCD160EC3- CZ/DZ (3 layers) | CPCD180EC5-Vo (5 layers) | CPCD180EC6-Vo (6 layers) | CPCD250EC7-VDG(7 layers) | CPCD250EC8-VDG(8 layers) | |
|---|---|---|---|---|---|---|---|
| Load capacity | kg | 4500 | 4500 | 8000 | 8000 | 9000 | 9000 |
| Load center | mm | 1220 | 1220 | 1220 | 1220 | 1220 | 1220 |
| Lifting height | mm | 6100 | 8100 | 14960 | 16200 | 16500 | 19000 |
| Mast angle(front/back) | deg | 3/6 | 3/6 | 3/6 | 3/6 | 3/3 | 3/3 |
| Overall width | mm | 3460 | 3460 | 3460/2440 | 3460/2840 | 4150 | 4150 |
| Wheel base | mm | 3650 | 3650 | 4000 | 4000 | 4250 | 4250 |
| Min. turning radius | mm | 4970 | 4970 | 4970 | 5600 | 5918 | 5918 |
| Max. lifting speed(with/without load) | mm/s | 330/400 | 330/400 | 470/480 | 470/480 | 590/600 | 590/600 |
| Max. travel speed(with/without load) | km/h | 30/30 | 30/30 | 31/31 | 31/31 | 28/29 | 28/29 |
