Specifications
Key Features:
- Engine options: Volvo | Cummins
- Parker hydraulics
- DANA transmission
- Kessler drive axles
- CAN-bus electronic controlling system
- Lifting capacities: 42,000kg | 46,000kg @ 1200mm load centre
Specifications:
| Model | Units | CPCD420 | CPCD460 | ||
| Load center | Mm | 1200 | |||
| Lifting capacity | kg | 42000 | 46000 | ||
| Lifting height (standard) | mm | 4000 | |||
| Lifting speed (at rated load) | mm/s | 260 | |||
| Lowering speed ( unloaded) | mm/s | 300-600 | |||
| Mast tilt (forward/backward) | Degrees | 6/10 | |||
| Engine | VOLVO | ||||
| Dimensions | Overall length(with fork) | Mm | 7930（10370） | ||
| Overall width | Mm | 4120 | |||
| Height | Cab | Mm | 4200 | ||
| Mast | mm | 4850 | |||
